Safety Guide
To avoid damage to the probe and inaccurate readings, do not use a current probe on a circuit that
exceeds the probe's maximum rated frequency or the maximum rated current at the measurement
frequency.
All current probes have a maximum current rating which may be derated depending on the
measurement frequency in accordance with the following table:
Probe
Probe maximum current by frequency
60 A pk max DC to 5 kHz,
TA018
derated to 15 A to 20 kHz
TA019
600 A pk max, DC to 400 Hz
2000 A pk max, DC to 200 Hz, derated to
TA167
200 A to 2 kHz, 20 A to 20 kHz
TA189
30 A pk max, DC to 100 kHz
TA234
30 A pk max, DC to 20 kHz
2000 A pk max, DC to 200 Hz, derated to
TA388
200 A to 2 kHz, 20 A to 20 kHz
TA408
100 A pk max, DC to 10 kHz
TA473
60 A pk max, DC to 50 kHz
TA496
60 A pk max, DC to 40 kHz
To prevent damage, always use and store your unit in appropriate environments as below.
Operating
Probe
temperature
TA018
32 to 104 °F
TA019
32 to 122 °F
TA167
32 to 122 °F
TA189
32 to 122 °F
TA234
41 to 122 °F
TA388
32 to 122 °F
TA408
32 to 122 °F
TA473
32 to 122 °F
TA496
32 to 122 °F
DO336-4
PicoScope 4225A and 4425A automotive oscilloscopes and accessories
CAUTION
CAUTION
Storage temperature
-4 to 158 °F
-4 to 158 °F
-4 to 185 °F
−4 to 185 °F
−4 to 158 °F
excluding battery
−4 to 185 °F
−4 to 185 °F
−4 to 185 °F
−4 to 158 °F
Auto power-off
Power supply/battery
no
no
yes
yes
no
N/A
N/A
N/A
N/A
Operating
Storage
humidity
humidity
0 to 70%
0 to 80%
0 to 70%
0 to 80%
Max 80% to 31 °C (87.8 °F)
decreasing linearly to 40% at
50 °C (122 °F)
0 to 80%
0 to 80%
15 to 85%
15 to 85%
15 to 85%
15 to 85%
15 to 85%
15 to 85%
0 to 70%
0 to 80%
Connection
6LR61 / PP3
6LR61 / PP3
6LR61 / PP3
6LR61 / PP3
6LR61 / PP3
Oscilloscope
PicoBNC+
Oscilloscope
PicoBNC+
Oscilloscope
PicoBNC+
Oscilloscope
PicoBNC+
Pollution
degree
2
2
2
2
2
2
2
2
BNC
BNC
BNC
BNC
BNC
Max
altitude
6560 ft
6560 ft
6560 ft
6560 ft
6560 ft
6560 ft
6560 ft
6560 ft
