HYVA HA10 Anweisungs- Bedienungs Und Wartungshandbuch Seite 160

HA10
E1M
E1
E2
HA15
E1
E2
HA22
E1
E2
E3
HA28
E1
E2
E3
HA33
E1
E2
E3
E4
SB: Senza basamento / Without base / Ohne Sockel
(*) :
Dato da calcolare caso per caso / Value to be calculated case by case / Von Fall zu Fall berechnender Wert
F Xf
[kg] [m]
SB: 87 SB: 0
BST: 200 BST: 0.232
BPS: 147 BPS: (*)
BSS: 163 BSS: 0
F Xf
[kg] [m]
SB: 116 SB: 0
BST: 229 BST: 0.203
BPS: 176 BPS: (*)
BSS: 192 BSS: 0
F Xf
[kg] [m]
SB: 145 SB: 0
BST: 258 BST: 0.180
BPS: 205 BPS: (*)
F Xf
[kg] [m]
SB: 167 SB: 0
BST: 317 BST: 0.194
BPS: 234 BPS: (*)
F Xf
[kg] [m]
SB: 180 SB: 0
STD: 318 STD: 0.195
EX: 352 EX: 0.220
D-34
G
Xg P Xp
[kg]
[m] [kg] [m]
49 0.596 490 1.89
58 0.656 490 1.89
77 1.088 315 2.77
G Xg P Xp
[kg]
[m] [kg] [m]
58 0.656 675 1.89
77 1.088 440 2.77
G
Xg P Xp
[kg]
[m] [kg] [m]
71 0.661 930 2.15
95 1.085 620 3.16
117 1.533 410 4.16
G
Xg P Xp
[kg]
[m] [kg] [m]
96 0.779 1220 2.25
128 1.201 820 3.24
154 1.578 605 4.24
G
Xg P Xp
[kg]
[m] [kg] [m]
121 0,852 1390 2,48
157 1,321 930 3,62
190 1,795 675 4,75
219 2,243 520 5,89
Gb TL
Ks
[kg] [kg]
15 613
1.2 613
20
394
30
Gb TL
Ks
[kg] [kg]
20 844
1.2
30 550
Gb TL
Ks
[kg] [kg]
22 1163
33 775
1.2
43 513
Gb TL
Ks
[kg] [kg]
33 1525
1025
47
1.2
57 756
Gb TL
Ks
[kg] [kg]
42 1738
57 1163
1.2
72 844
83 650
