Replacing the flexible plate
H
UN41-0514MM
For this operation, proceed as outlined below.
1) Unscrew the screws (A).
2) Remove the casing (B).
3) Loosen the wing nut (C).
4) Turn the lock lever (D).
5) Push the share forwards and turn it so it is facing
downwards.
6) Release the springs (E).
7) Unscrew the screws (H).
8) Remove the flexible plate (L).
9) Fit the new flexible plate in position.
10) Tighten the screws (H).
11) Hook up the springs (E).
English language
INFORMATION CONCERNING REPLACEMENTS
A
L
M
12) Make sure the flexible plate is centred (see "Sym-
13) Check the position of the flexible plate with respect
14) Tighten the screws (H).
15) Refit the share in the work position.
16) Check that the Plant Control device (M) is inside the
17) Make sure that the share is secured in place with the
18) Tighten the wing nut (C).
19) Position the casing (B).
20) Tighten the screws (A).
42
B
C
metrical adjustment of the flexible plate with the
ploughshare").
to the share (see "Adjusting the flexible plate posi-
tion with the ploughshare").
share.
lock lever (D).
8
D
E
