Seat positioning
D
UN41-0502MM
Poor work posture will tire the operator and could lead
to mistakes being made; therefore, before starting work,
adjust the seat and secure it in the position that offers
maximum comfort.
English language
INFORMATION FOR USE
A
B
C
29
Proceed as outlined below.
A) Lever: this is used to adjust the seat lengthways.
Release the lever and then move the seat forwards or
backwards.
Secure the seat in the right position using the lever.
B) Lever: this is used to adjust the seat tilt.
Release the lever and then tilt the seat forwards or
backwards.
Secure the seat in the right position using the lever.
C) Screws: these are used to adjust the seat height.
Loosen the screws and adjust the seat height.
Tighten the screws to secure the seat in the right po-
sition.
D) Nuts: these are used to position the seat on the
planting unit centrally.
Loosen the nuts, shift the seat, and then position it in
the centre of the planting unit.
Tighten the nuts to secure the seat in the right posi-
tion.
