Proline Promag 55 PROFIBUS DP/PA
Endress+Hauser
Nennweite ASME Schrauben
Druck-
stufe
[inch]
3" Class 300
4" Class 150 8 × 5/8"
4" Class 300
6" Class 150
6" Class 300 12 × ¾"
8" Class 150
10" Class 150 12 × 7/8"
12" Class 150 12 × 7/8"
14" Class 150 12 × 1"
16" Class 150 16 × 1"
18" Class 150 16 × 1 ¹⁄₈"
20" Class 150 20 × 1 ¹⁄₈"
24" Class 150 20 × 1¼"
Schrauben-Anziehdrehmomente Promag S für JIS B2220, 10/20K
Nennweite JIS Schrau-
Druckstufe
[mm]
15 10K 4 × M 12
15 20K 4 × M 12
25 10K 4 × M 16
25 20K 4 × M 16
32 10K 4 × M 16
32 20K 4 × M 16
40 10K 4 × M 16
40 20K 4 × M 16
50 10K 4 × M 16
50 20K 8 × M 16
65 10K 4 × M 16
65 20K 8 × M 16
80 10K 8 × M 16
80 20K 8 × M 20
100 10K 8 × M 16
100 20K 8 × M 20
125 10K 8 × M 20
125 20K 8 × M 22
150 10K 8 × M 20
150 20K 12 × M 22
200 10K 12 × M 20
200 20K 12 × M 22
250 10K 12 × M 22
250 20K 12 × M 24
300 10K 16 × M 22
300 20K 16 × M 24
Naturgummi Polyurethan
[lbf · ft] [lbf · ft]
8 × ¾" –
11
8 × ¾" –
8 × ¾" 24
–
8 × ¾" 38
42
58
77
75
108
105
161
ben
Naturgummi Polyurethan
[Nm] [Nm]
–
–
–
–
–
–
–
–
–
–
18
–
10
–
12
–
20
–
25
–
23
–
39
– 144
38
– 124
Max. Anziehdrehmoment
PTFE PFA
[lbf · ft] [lbf · ft]
19 35 31
23 41 37
30 49 44
44 78 63
38 54 49
59 105 80
55 100 –
76 131 –
117 192 –
111 181 –
173 274 –
160 252 –
226 352 –
Max. Anziehdrehmoment
PTFE PFA
[Nm] [Nm]
– 16 –
– 16 –
19 32 27
19 32 27
22 38 –
22 38 –
24 41 37
24 41 37
33 54 46
17 27 23
45 74 63
23 37 31
23 38 32
35 57 46
29 47 38
48 75 58
51 80 66
79 121 103
63 99 81
72 108 72
52 82 54
80 121 88
87 133 –
212 –
63 99 –
183 –
Montage
Hartgummi
[lbf · ft]
28
31
43
58
52
79
75
98
100
94
150
135
198
Hartgummi
[Nm]
–
–
–
–
–
–
–
–
40
20
55
28
29
42
35
56
60
91
75
81
61
91
100
159
74
138
