Setting the parameters / General settings (awning)

Menu
Motor controls (Actor = X-line tubular Motor)
Use scenes (see chapter „Scenes")
Transmission delay of switching / status outputs after restoration of voltage

Controlling an awning / Awning drive mechanism

The specific characteristics of the connected drive are detailed here.
Menu
Exchange Up/Down
Use tilting *
Automatic length balancing of hangings
Send drive position after change
If „Yes": Transmission delay of the position in 0,1 sec
* see page 51 (Functional description)
IMPORTANT
„Automatic length balancing of hangings" must always be set to „No" for awnings.
Settings
Roller shutter • Awning
No • Yes
5 sec ... 2 h
Settings
No • Yes
No • Yes
No
No • Yes
0 ... (10) ... 50
