Roller shutter automatic
Shading automatic
Menu
Position of sun
Evaluate the position of the sun
If „Yes": Position of the sun is defined by
If "Discrete
Azimuth from
values of azimuth
Azimuth up to
and elevation":
Elevation from
Elevation up to
If "directions (in
Direction
terms of azimuth/
elevation):
Movement position
Roller shutter position in %
Use learning object for new shading position
If „Yes" is selected for „Use learning object for new shading position", then a sunshade posi-
tion can be learned. In order to do so, first move manually to an arbitrary position and then
learn with „shading position learning object" via communication object no. 41. The learned
position is then automatically assumed by the automatic system in the event of sunlight.
Settings
No • Yes
Discrete values of azimuth and elevation •
directions (in terms of azimuth/elevation)
0 ... 360
0 ... 360
0 ... 90
0 ... 90
East (Azimuth: 0° ... 180°) •
Southeast (Azimuth: 45° ... 225°) •
South (Azimuth: 90° ... 270°) •
Southwest (Azimuth: 135° ... 315°) •
West (Azimuth: 180° ... 360°)
0 ... (75) ... 100
No • Yes
