Awning automatic
Under „Automatic mode" the setting „Internal automatic mode" was selected for „Awning control".
Outdoor temperature block
Menu
Use outdoor temperature block
If „Yes":
Type of temperature input object
If „1 Bit":
Permits shading if bit = 0
Blocks shading if bit = 1
If „16 Bit":
Treshold value in 0.1 ° C
Hysteresis in 0.1 ° C
Blocks shading if MV < TV
Permits shading if MV > TV + HY
Send current blocking status
Dawn and time control
Menu
Use dawn and time control
If „only dawn
Type of dawn input object
control":
If „1 Bit":
Switching delay
If„16 Bit":
Dawn treshold value in lux
Switching delay
Send current dawn status
If „only time
Time control only by means of communication object
control":
If „both (OR
Excecute settings as shown above
gating)":
Settings
No • Yes
1 Bit • 16 Bit
-300 ... (50) ... 800
1 ... (20) ... 100
No • Yes
Settings
No • only dawn control • only time control • both
(OR gating))
1 Bit • 16 Bit
1 minute
1 ... (10) ... 1000
1 minute
No • Yes
EN
83
