Communications protocol

Abbreviations / flags:
C = Communication
R = Read
W = Write
T = Transfer
U = Update

Listing of all communications objects

No Name Function
0 Manual long-term Input
1 Manual short-term Input
2 Manual movement position Input
4 Automatic long-term Input
5 Automatic short-term Input
6 Automatic operating position Input
8 Status automatic or manual UINT1 Output
9 current movement position UINT8 Output
11 Recall / Storage of scenes Input
12 Alarm object Input
13 Blocking object 1 Input
14 Wind blocking object Input
15 Wind block measured value Input
16 Wind block status Input
17 Blocking object 2 Input
18 Rain blocking object Input
19 Change from manual to Input
automatic
20 Automatic blocking object Input
21 Outdoor temperature blocking UINT1 Input
22 Outdoor temperature block UINT16 Input
measured value
23 Outdoor temperature block status UINT1 Output
24 Dawn object UINT1 Input
25 Dawn measured value UINT16 Input
26 Dawn status UINT1 Output
27 Time control UINT1 Input
28 Indoor temperature release object UINT1 Input
29 Indoor temperature release UINT16 Input
measured value
30 Indoor temperature release UINT16 Input
target value
31 Indoor temperature release status UINT1 Output
32 Shading object UINT1 Input
33 Shading brightness UINT16 Input
measured value 1
34 Shading brightness UINT16 Input
measured value 2
35 Shading brightness UINT16 Input
measured value 3
36 Shading threshold value UINT16
Input/Output
Flags DP Type
C R W 1.008
C R W 1.007
C R W 5.001
C R W 1.008
C R W 1.007
C R W 5.001
C R T 1.002
C R T 5.001
C R W 18.001
C R W 1.003
C R W 1.003
C R W 1.003
C R W 9.005
C R T 1.002
C R W 1.003
C R W 1.003
C R W 1.002
C R W 1.003
C R W 1.003
C R W 9.001
C R T 1.002
C R W 1.003
C R W 9.004
C R T 1.002
C R W 1.002
C R W 1.003
C R W 9.001
C R W 9.001
C R T 1.002
C R W 1.003
C R W 9.004
C R W 9.004
C R W 9.004
C R W T 9.004
No Name Function
37 Shading threshold value UINT1 Input
1 = +1 / 0 = -1
38 Shading threshold value + UINT1 Input
39 Shading threshold value - UINT1 Input
40 Shading status UINT1 Output
41 Shading position learning object UNIT1 Input
42 Azimuth UINT16 Input
43 Elevation UINT16 Input
124 Software_version Readable
125 Gerneral malfunction Output
126 Obstacle detected Output
127 Blocked Output
EN
Flags DP Type
C R W 1.007
C R W 1.017
C R W 1.017
C R T 1.002
C R W 1.017
C R W 9.*
C R W 9.*
C R 5.010
C R T 1.002
C R T 1.002
C R T 1.002
69
