DSX Touch
5. Installation
Figure A:
Installation with adhesive tape
EN
Figure B:
Optional installation with dowels and screws

Mounting the remote control's wall bracket

• Before attaching the wall bracket to the wall, ensure that the remote control has
radio contact to the instantaneous water heater from its designated position.
• The wall bracket of the remote control can either be attached securely with the
included adhesive tape, after stripping off the protection film (as shown in the fig­
ure A), on a rigid board (e.g. tile) or with suitable dowels (Ø 4 mm) and screws (as
shown in the figure B).
• When mounting with adhesive tape, ensure that the mounting surface is dry and
free of grease and soap.
• When using the adhesive tape it is not possible to further adjust the position
because of the strong adherence of the glue. Therefore, pay attention to a horizon­
tal alignment when attaching it.
• The remote control is magnetically retained at the wall bracket.
• Keep the remote control and wall bracket away from credit cards or other cards
with magnetic strips. The built in magnets can damage the card's magnetic strip.
Note: Do not expose the remote control to moisture.
52
