3.5.2 Suction heights for media with maximum permissible
viscosity
Applies to:
• Newtonian liquids
• non-degassing and non-abrasive media
• temperature of 20 °C
• standard pump version.
Pump type
Single pump
DMX 24-8
DMX 52-8
DMX 100-8
DMX 142-8
DMX 37-5
DMX 82-5
DMX 160-5
DMX 224-5
DMX 60-3
DMX 130-3
DMX 255-3
DMX 380-3
DMX 67-10
DMX 132-10
DMX 190-10
DMX 190-8
DMX 95-8
DMX 199-8
DMX 280-8
DMX 280-6
DMX 152-6
DMX 321-6
DMX 321-4
DMX 460-6
DMX 460-3.5
DMX 249-3
DMX 315-3
DMX 525-3
DMX 765-3
12
Double pump
DMX 24-8/24-8
DMX 52-8/25-8
DMX 100-8/100-8
DMX 142-8/142-8
DMX 37-5/37-5
DMX 82-5/82-5
DMX 160-5/160-5
DMX 224-5/224-5
DMX 60-3/60-3
DMX 130-3/130-3
DMX 255-3/255-3
DMX 380-3/380-3
DMX 67-10/67-10
DMX 132-10/132-10
DMX 190-10/190-10
DMX 190-8/190-8
DMX 95-8/95-8
DMX 199-8/199-8
DMX 280-8/280-8
DMX 280-6/260-6
DMX 152-6/152-6
DMX 321-6/321-6
DMX 321-4/321-4
DMX 460-6/460-6
DMX 460-3.5/460-3.5
DMX 249-3/249-3
DMX 315-3/315-3
DMX 525-3/525-3
DMX 765-3/765-3
Max. stroke rate Maximum viscosity
[n/min] [m Pas]
29
63
120
168
29
63
120
168
29
63
120
168
57
120
175
175
57
120
175
175
57
120
120
175
175
57
72
120
175
Intake height
[mWC]
1000 1
700 1
400 1
200 0
600 1
500 1
200 0
150 0
500 0
400 0
100 0
50 0
700 1
400 1
200 0
200 0
500 1
200 0
150 0
150 0
400 0
100 0
100 0
50 0
50 0
100 0
100 0
50 0
10 0
