3 Technical data

Sizes (cm)
Heel height with slim
footshell (mm)
Heel height with nor-
mal footshell (mm)
System height with
slim footshell (mm)
System height with
normal footshell (mm)
Weight with slim
footshell (g)
Weight with normal
footshell (g)
Body weight MG3
up to
Body weight MG4
up to
Mobility Grade
4 Handling
4.1 Installing the Harmony 2R117 Socket Connector
On a new socket, drill a 6mm (¼") hole into the socket at a distal, posterior position. For sockets
with a 4R136 or 4R138=5 Ottobock One-Way Valve, remove valve from socket and drill into exi-
sting hole. Remove burrs from the inside of the socket. Lightly sand the exterior of the socket with
medium grit sandpaper to roughen the bonding surface. Wipe with isopropyl alcohol to clean the
bonding surface. Also clean the 2R117 Socket Connector with isopropyl alcohol.
Next, apply a thin coating of adhesive (Ottobock recommends 2 Component Urethane Adhesive
SL=P091) to the flat surface of the flange as well as the collar. Be careful not to get adhesive in
the tapered end.
Insert tapered end of flange into the 6mm (¼") hole with the tube directed towards the Harmony
Pump. Use needle nose pliers to pull the tapered end of flange into the socket until the flat surface
of the flange is tight against the outer surface of the socket. Tape the flange in place with vinyl
tape. Allow to cure for at least 45 minutes.
Note: For particularly deep or narrow sockets, the tapered flange can be marked with a pen
first, then removed and cut. This may require a slightly larger hole (6,5mm or ¼˝). Glue as with
normal socket.
Use a round-edge knife to trim the tapered end of the flange inside of the socket. It should be flush
with the inside surface of the socket.
21 22 23
15 15 15
– – –
163 164 166
– – –
790 800 860
– – –
100 kg/220 lbs
100 kg/220 lbs
3+4
24 25 26
15 15 15
10 10 10
167 175 177
173 175 177
890 940 960
900 950 980
150 kg/330 lbs
125 kg/275 lbs
27 28 29
15 – –
10 10 10
177 – –
181 183 189
1020 – –
1030 1050 1110 1140
