CONTENTS
1. Symbols used in this document
2. Introduction
3. Installation
3.1 Installation of pressure transmitter
3.2 Connections to LC, LCD 108
3.3 Connections to LC, LCD 110
4. Setting and operation
4.1 Setting
5. Technical data
6. Disposal
Warning
Prior to installation, read these installation
and operating instructions. Installation and
operation must comply with local
regulations and accepted codes of good
practice.

1. Symbols used in this document

Warning
If these safety instructions are not
observed, it may result in personal injury.
Warning
If these instructions are not observed, it
may lead to electric shock with consequent
risk of serious personal injury or death.
If these safety instructions are not
Caution
observed, it may result in malfunction or
damage to the equipment.
Notes or instructions that make the job
Note
easier and ensure safe operation.

2. Introduction

The LT 200 is a unit enabling the use of an analog
4-20 mA pressure transmitter for registration of level
together with Grundfos controllers, types LC, LCD
108 and 110, instead of rod electrodes and float
switches.
The unit has four digital outputs with individual
setpoints and shows the actual level.
