Start M1, M2, M3, M4, M5, M6
Anterior seat height (in cm)
without wider foot space
Caster fork, short
Position
5"
5.5"
Caster diameter 6"
7"
8"
Caster fork, long
Position
5"
5.5"
Caster diameter 6"
7"
8"
* Indications without seat cushion and with a seat inclination of 0°
Anterior seat height-posterior seat height<=3.5 cm
Casters in dependency of the anterior seat height
Caster fork in dependency of the anterior seat height and casters
Rear wheel size in dependency of the posterior seat height
Start M1, M2, M6

Posterior seat height (in cm)

Posterior seat height
20"
Rear
22"
wheel size
24"
Start M4, M5
Posterior seat height (in cm)
Rear wheel size
Free mounting
positions
22"
1 38
2 41
3 44
4 47
Setting range*
40-44
42-45
42-45
45-47
47-48
Setting range*
42-46
42-47
43-47
44-49
46-50
Setting range
35-45
37-47
43-50
24"
41
44
47
50
Start M3
Anterior seat height (in cm)
wider foot space
Caster fork, short
Position
5"
5.5"
Caster diameter 6"
7"
8"
Caster fork, long
Position
5"
5.5"
Caster diameter 6"
7"
8"
* Indications without seat cushion and with a seat
inclination of 0°
With the option "without wider foot space", the anterior
seat height values of the M5 apply.
Anterior seat height-posterior seat height<=3.5 cm
Casters in dependency of the anterior seat height
Caster fork in dependency of the anterior seat height
and casters
Rear wheel size in dependency of the posterior seat height
Setting range*
36-41
39-42
39-42
42-44
44-45
Setting range*
40-44
41-45
42-46
43-47
44-48
