9 Technical Data

Overall length (in cm)

20x1 3/8"
Rear axle po-
Module
sition
M1 -
M2, M3 -
M4 -
M5 -
M6 89.5

Overall width (in cm)

Seat Standard rear wheel
width max.
28 47
30.5 49.5
33 52
35.5 54.5
38 57
40.5 59.5
43 62
45.5 64.5
48 67
50.5 69.5
53 72
55.5 74.5
58 77
Applicable to push ring attachment, narrow (for push ring attachment, wide: +2 cm) and a 0° camber of the
1)
rear wheels.
60
Rear wheel size
22x1 3/8"
Front axle po- Rear axle po-
sition sition
- 100
- 100.5
- 100.5
- 97.5
79 92
1)
Rear wheel with drum
brake max.
49.5
52
54.5
57
59.5
62
64.5
67
69.5
72
74.5
77
79.5
24x1 3/8"
Front axle po- Rear axle po-
sition sition
90 103.5
90 104
87.5 104
81.5 101
81.5 95.5
Front axle po-
sition
94
94
91
85
85
