primes HP-MSM-I Originalbetriebsanleitung Seite 141

HP-MSM-I Parallel/PROFIBUS
Reg. Profibus-
Adr. Adresse
9 ResPG 18.0+1
18.2+3
18.4+5
18.6+7
19.0
19.1
19.2
19.3
19.4-6
19.7
10 Results 20+21
11 22+23
12 24+25
13 26+27
14 28+29
15+16 30-33
17 34+35
18 36+37
19 38+39
20 40+41
21 42+43
22-25 44-51
Revision 02/2018 DE
®
Name Funktion/Beschreibung
2 bit PG1 Protection Glass 1 - Condition (0: untested;
1:dirty; 2: undefined; 3: clean)
2 bit PG2 Protection Glass 2 - Condition (0: untested;
1:dirty; 2: undefined; 3: clean)
2 bit PG3 Protection Glass 3 - Condition (0: untested;
1:dirty; 2: undefined; 3: clean)
2 bit PG4 Protection Glass 4 - Condition (0: untested;
1:dirty; 2: undefined; 3: clean)
3 bit ActPG Actual Protection Glass - Number of the
current protective window
2 byte EvalResult Evaluation result of last measurement
("Ampel": 0=rt; 1=gb; 2=gn)
2 byte ElCalDev Deviation electric calibration
2 byte PwrPro Result of last power measurement at
process entrance
2 byte PwrFib Result of last power measurement at fibre
entrance
2 byte FocRad Combined focus radius of last caustic
measurement (w0)
4 byte FocPosZ Focusposition in Z (Z0)
2 byte BeamParamProd Beam Parameter Product
2 byte Deviation Standard Deviation
2 byte Rayleigh Rayleigh length (Zr)
2 byte Divergence Divergence
2 byte FocShift Focus shift of last measurement
8 byte Reserved
PRIMES
32byte
MainResultsModul
141
