Technical data
Start M1, M2, M4, M5, M6, Asia
Anterior seat height (in cm)
without foot space enlargement
Caster fork, short
Position
5"
5.5"
Caster
diameter
6"
7"
Caster fork, long
Position
5"
5.5"
Caster
6"
diameter
7"
8"
1) Specified at 0° seat angle, without seat cushion
• Anterior seat height - posterior seat height <= 3.5 cm
• Casters in dependency of the anterior seat height
• Caster fork in dependency of the anterior seat height and casters
• Rear wheel size in dependency of the posterior seat height
Start M1, M2, M3, M6, Asia
Posterior seat height (in cm)
Posterior seat height Setting range
Rear wheel size
86 | Ottobock
Setting range
1)
40 – 44
42 – 44
43 – 45
45 – 47
Setting range
44 – 47
44 – 48
45 – 49
47 – 50
48 – 51
20" 37 – 43
22" 38 – 45
24" 41 – 49
M1 Intro · M2 Effect · M3 Hemi · M4 XXL · M5 Comfort · M6 Junior · Asia
Start M3
Anterior seat height (in cm)
with foot space enlargement
Caster fork, short
Position
5"
5.5"
Caster
diameter
6"
7"
Caster fork, long
Position
5"
5.5"
Caster
6"
diameter
7"
8"
Start M4, M5
Posterior seat height (in cm)
Free mounting
positions
1
2
3
4
Setting range
1)
38 – 40
39 – 41
40 – 42
42 – 43
Setting range
41 – 44
42 – 45
42 – 45
44 – 47
45 – 48
Rear wheel size
22" 24"
38 41
41 44
44 47
47 50
