3.7 Attached illustrations
The attached illustrations are common for all language versions. They can be found at the end of this manual in Chapter 6 on page 87.
High-resolution colour pictures are included in the electronic version of these operating instructions, which available for download from our
web pages.
Fig. 1: Machine packaging
1) Upper chassis
2) Bottom chassis with the bumper and the hitch
3) Handlebars support post with the integrated fuel
tank
4) Handlebars
5) Tightening nut for vertical adjustment of the
handlebars
6) Handlebars horizontal adjustment pin
7) Engine
8) Three-way fuel valve
Fig. 2: Description of the machine
Fig. 3: Vertical adjustment of the handlebars
Fig. 4: Horizontal adjustment of the handlebars
Fig. 5: Switching between the Manual and Motorized
Travel
Fig. 6: Control elements on handlebars
Fig. 7: Travel Speed Selection
1) STOP:
The engine is not running.
➢
It is used to turn off the running engine,
➢
when the machine is parked,
➢
when refuelling,
➢
when transporting the machine.
3) MAX:
"Rabbit" position
The engine runs at its maximum speed.
➢
Working position
Fuel system
1) Three-way valve that allows to close the supply of fuel to the engine
2) Auxiliary fuel tank 4.5 litres
3) Engine fuel tank 1.1 litre
4) Fuel tank cap with the bleeder
5) Fuel filter integrated in the fuel hose.
Fig. 9: Fuel system
The Z-02 pin is not included in the supply of the
121001.
Fig. 10: Attaching the Tools to the Rear of the
Machine
Fig. 11: Bowden adjustment screws
Fig. 12: Attachment tool drive clutch lever – setting
Fig. 13: Travel clutch lever – setting
Fig. 14: Safety Pictograms
Spark plug spanner 21 mm (3/8")
HONDA petrol can
Ordering No. 4359
VARI POWERMETER operating hours counter
Ordering No. 4227
Fig. 15: Recommended Tools and Accessories
54
The point for supporting the machine
9) Fuel tank cap with the bleeder
10) K46ED hydrostatic gearbox
11) Left wheel
12) Right wheel
13) Travel clutch lever
14) Attachment drive clutch lever
15) Safety lock
16) Service brake lever
Fig. 2: Description of the machine
ON position – engine-driven travel
Forward
2) MIN:
"Turtle" position
The engine runs at its idle speed.
4) CHOKE
„choke" position
engine running at lower speed.
1 The arrow points to the right, marked with OFF – the fuel system is
completely closed
2 The arrow points upwards, engine silhouette – the engine uses the fuel
from the engine tank
3 The arrow points downwards, auxiliary tank silhouette – the engine uses the
fuel from the auxiliary tank
Maximum level of fuel
RAPTOR Hydro K carrier; it is necessary to separately purchase it as accessories under the ordering No:
ANV-200 trailer
Ratchet handle 3/8"
HONDA fuel stabilizer
Ordering No. 08CXZ-FSC-250
JANETTE Type (150 ml) rinse syringe - for sucking
out the oil
17) Throttle levers
18) Speed selector lever
19) Scale and arrow
20) Bypass lever (OFF-ON)
21) Front attachment point
22) Rear attachment point
23) Attachment drive belt pulley
Neutral
➢
Short work break.
➢
Cold engine start.
AV-650 sulky
12-point socket – 3/8" - 15 mm
12-point socket – 3/8" - 17 mm
Briggs & Stratton Fuel Fit™ fuel stabilizer (Ordering
No. 992381)
Z-01 pin
Ordering No. 121001
RAPTOR Hydro K
OFF position – manual travel
Reverse
