Before commencing the work with the machine, leave the engine running for so long that it gets sufficiently warm.

Suction holes for cooling air on the manual starter should be closed with the self-adhesive tape. The engine will then
warm up more quickly and it will be more thermally stable during the work.
3.5 Maintenance, Care, Storage

Owing to the weight of the machine, all maintenance and adjustment should be performed by two people.
To secure a long-term satisfaction with our product, it is necessary to provide it with due care and maintenance. By providing regular
maintenance you will reduce its wear and you will secure correct operation of all its parts.
Observe all instructions concerning maintenance and adjusting intervals. We recommend that you keep records of operating hours and the
conditions under which the machine is used (these may be useful for servicing centres). We recommend that you have the post-season
maintenance implemented by one of our authorized service centres; the same applies to standard maintenance if you are not certain of
your technical capabilities.

The good help to monitor operating hours is the VARI PowerMeter device. This accessories can be bought with every
dealer of VARI products.

Prior to each use of the device, check the tightening of the bolts fastening the attachment, its work tool and all
screwed connections of guards, covers and the motor!

Replace the lost screwed connections with the original parts that are designed for the given spot. By using
unoriginal low-quality parts, you expose yourself to the risk of injury or damage to the machine!
3.5.1 Recommended Tools and Accessories
For assembling and maintenance of the machine, we recommend the below stated accessories and tools
Open-end spanner (wrench) 10 mm - 1x
Open-end spanner (wrench) 13 mm - 1x
Open-end spanner 15 mm, narrow - 1x
12-point socket 15 mm, 16 mm - 1x
Bent ratchet handle 3/8"
Spark plug spanner 16 mm (3/8") - 1x
Table 34: Recommended Tools and Accessories
3.5.2 Travel Wheels
3.5.2.1 Tyre Pressure
For proper operation and to ensure a long service life of the travel wheels, especially the tyres, it is necessary to check the tyre pressure.
Perform the check before starting to work with the machine. Before parking the machine for a longer time, inflate the tyre to the
value (see below). Keep the same pressure in the left and right wheels – the machine better holds a straight track.

Do not exceed the maximum tyre pressure – there is a risk of the tyre explosion!

If the pressure in the tyre is low, the inflation valve on the tube may get cut off.

MAX imum (recommended) tyre pressure: 25 PSI (172 kPa or 1.724 bar or 1.7 atm or 0.172 Mpa)

MIN imum
If there is a permanent tyre pressure leakage, make sure that there is no defect on the tyre tube – repair it if necessary.

If you are not sufficiently manually skilled, have the operations done by an authorized service centre.
3.5.3 Machine Lubrication

When working with lubricants, observe the basic hygiene regulations and observe the environmental protection
regulations and laws.
It is not included in the product supply; it is necessary to buy it separately.
74
75 If the tyre pressure is lower than the minimum, the tyre-casing structure will be damaged and the service life will be significantly reduced.
48
TOOLS
75 allowed tyre pressure: 18 PSI (124 kPa or 1.24 bar or 1.22 atm or 0.124 Mpa)
ACCESSORIES
Petrol can, capacity 5 litres, HONDA (Ordering No. 4359)
HONDA fuel stabilizer (Ordering No. 08CXZ-FSC-250)
Briggs & Stratton Fuel Fit™ fuel stabilizer (Ordering No. 992381)
VARI POWERMETER operating hours counter (Ordering No. 4227)
Z-02 pin (Ordering No. 121001)
Supporting leg RON (Ordering No. 4507)
RAPTOR Hydro K
- Fig. 15 on page 92 .
74
MAX
