3.3 Basic Information
3.3.1 Use of the Machine
The RAPTOR Hydro K multifunctional carrier is intended to provide drive (while at the same time ensuring the movement of the whole
assembly) for various work tools that can be attached to the front or the rear of the machine. The attached tools may be propelled by the
engine through the clutch that can be disengaged and that has got the integrated brake, or pushed or towed.
Name Type
Mulcher RMS-600
Drum lawn mower RBS-700
Hay tedder ROP-115
Dozer blade RSR-1000
Sulky (the carriage
AV-650
with the seat)
The single-axle
ANV-200
trailer
Wheel weight -
Snow chains -
Supporting leg RON
Brush cutter RBS-700D
Sweeping brush RKV-1000
Snow blade ROR-1000
Table 31: Attachments
63

The use for purposes other than the intended purpose is; therefore, to be considered a use for an unspecified
purpose!
3.3.1.1 Technical Data
Description
Length x width x height
Weight
Safe slope operation
Travel speed
Clutch
Table 32: Technical data for the RAPTOR Hydro carrier
3.3.1.2 Engine Information

Further information about the motor not stated here is available at the motor manufacturer's website.
Engine
Type
Maximum (set) speed of the motor
Maximum / short term 65 tilting of the motor
Fuel tank capacity
Fuel
Motor oil filling
Type and quality of the oil
Tab 2: Basic details of the engine
63 All the attachments specified in the chart are not part of the RAPTOR Hydro product. They are separate products. Contact your dealer or visit the web pages of the manufacturer
www.vari.cz or our facebook profile at https://www.facebook.com/VARIcz/ for the information on the dates of introducing individual attachments to the market.
For more information on the engine, including spare parts numbers, visit
64
CW10/2020.
Short term - up to one minute.
65
66 Due to ever increasing proportion of BIO-components in fuel, use fuel stabilizer recommended directly by the manufacturer of the engine for the given type of the engine.
42
Ordering No. Description
The work tool for cutting scraggly grass, including self-seeded trees up to the diameter of
4471
1.5 cm.
4472 The attachable work tool for cutting maintained meadow-like grassy areas.
The tool is intended for hay tedding and raking of the cut grass into rows on grassy
4477
meadow-like areas.
4478 The attachment for removing freshly fallen snow.
The attachable adapter with the seat for the operator (the sulky) that can be used in
4217
conjunction with tools attached to the front of the machine.
4475 The trailer serves for transporting attachable adapters or various material.
The weight serving to increase adhesion of the carrier when travelling with the single-axle
4473
trailer and during the work with adapters in difficult conditions.
4476 Intended to improve adhesion on snow; suitable for the tools for winter maintenance
4507 Leg for supporting the machine when no adapter is connected
Adapter for cutting thin-blade grass plots and woody underbrush in a forest and on a
4475
meadow
4508 Adapter for removing solid impurities or new-fallen snow.
Adapter for the RKV-1000 sweeping brush, for removing snow to the side on front of the
4519
brush.
Unit Value
mm 1350x660x1160
kg 71
 10°
0 - 8 forward
km.h -1
1.5 reverse
Single-plate
- NORAM VARI
Integrated brake
Unit RAPTOR Hydro K
-
min -1

l (litre)
petrol
l (litre)
-
Description
Gearbox
Oil filling volume in the
gearbox
Type and quality of the oil
- normal load
- higher thermal load
Tyres
Inflation
MAX PSI; kPa; atm
MIN
KOHLER Command PRO CV224-3014
as recommended by the engine manufacturer – see the engine operating instructions.
https://kohlerpower.com/en/engines/product/command-pro-cv224
Unit Unit
type TUFF TORQ K46ED
l (litre)
type; API;
Petroleum engine oil; SL/CF; 10W-30
SAE
Synthetic engine oil; SL/CF; 5W-50
GRASS TRACK chevron tread pattern
-
4.00-8 62F 4PR tube type
25; 172; 1,70
18; 124; 1,22
64
3200 -100
20° / 30°
1.2.2020
Oct. No. 91-95 66
0.6
RAPTOR Hydro K
Active Passive
X
X
X
X
X
X
X
X
X
X
X
X
2.3
- the link modified in
