1 Netztransformator
240 VAC/ 2 x 12V
120 VAC/ 2 x 12V
240 VAC/ 2 x 12V
2 Akustische Signalgeber
3 Membrane, PTFE
4 Überwurfmutter, PVDF
5 O-Ring, EPDM
6 O-Ring, EPDM
7 Anschlussteil, Saugventil
8 Anschlussnippel
9 Schneidring, NW 12
10 O-Ring, EPDM
11 Anschlussteil
12 Ventileinsatz
13 O-Ring, EPDM
14 O-Ring, EPDM
15 O-Ring, EPDM
16 Kugel ∅ = 8 mm, 1.4401
17 Kegeldruckfeder
18 Plattenventil
19 Saugventileinsatz
20 Ventiloberteil
21 Kondensatorplatine
22 CDI 01 – Steuerplatine
23 Pumpenkopf
Sauganschluss
Saugventileinsatz
Druckventil
Druckanschluss
Zusatzplatine
Netztrennmodul
12

Anhang

- Klemmenbelegungsplan
- Übersicht „Programmierstruktur"
12.1 Klemmenbelegungs-
pläne CDI 01
Anschlußschema CDI 01
Basisversion
1 Mains transformer
240 VAC/ 2 x 12V
120 VAC/ 2 x 12V
240 VAC/ 2 x 12V
2 Piezo buzzer
3 Seal washer, PTFE
4 Union nut, PVDF
5 O-ring, EPDM
6 O-ring, EPDM
7 Connection item, suction valve
8 Connection nipple
9 Cutting ring, NW 12
10 O-ring, EPDM
11 Connection item
12 Valve insert
13 O-ring, EPDM
14 O-ring, EPDM
15 O-ring, EPDM
∅
16 Ball = 8 mm, 1.4401
17 Cone thrust spring
18 Disc valve
19 Suction valve insert
20 Valve top
21 Condensator PCB
22 CDI 01 - PCB
23 Pump head
Suction connection
Suction valve insert
Pressure valve
Pressure connection
Additional PCB
Interface module
12

Appendix

- Plan of terminal connections
- Programming overview
12.1 Plans of terminal
connections CDI 01
Connecting scheme CDI 01
basic version
Sid 42
1 Huvudtransformator
240 VAC/ 2 x 12V
120 VAC/ 2 x 12V
240 VAC/ 2 x 12V
2 Summerton
3 Membrantätning, PTFE
4 Mutter, PVDF
5 O-ring, EPDM
6 O-ring, EPDM
7 Anslutningsdel sugventil
8 Anslutningsnippel
9 Låsbricka NW 12
10 O-ring, EPDM
11 Anslutningsdel
12 Ventilinsats
13 O-ring, EPDM
14 O-ring, EPDM
15 O-ring, EPDM
∅
16 Kula = 8 mm, 1.4401
17 Konisk säkringsfjäder
18 Plattventil
19 ingång sugventil
20 ventiltopp
21 Kondensatorplint
22 CDI 01-manöverkort
23 Pumphuvud
Suganslutning
Ingång sugventil
Tryckventil
Tryckanslutning
Extra manöverplint
Anslutningsplatta
12

Bilaga

- Kopplingsschema
- Översikt "Programmering"
12.1 Plan för
terminalanslutningar

CDI 01

Plan de raccordement CDI 01
version de base
41.8931.009
41.8931.015
41.8931.016
41.8271.008
2.406.17
3.4800.142
41.7001.170
41.7001.080
3.4060.144
3.4800.159
3.4040.107
41.7001.081
3.4060.143
3.2170.147
41.7001.034
3.2400.104
41.7001.101
41.4203.031
3.0610.108
3.0590.309
3.2170.163
3.4060.138
2.235.56
2.235.90
2.240.33
2.279.47
2.279.33
2.406.13
2.279.46
2.235.52
2.235.95
