4 Familiarising yourself with your appliance
Familiarising yourself with your appliance
4.1 Control panel
You can use the control panel to configure all functions of your appliance and to obtain information about the operat-
ing status.
Note: On certain models, specific details such as colour and shape may differ from those pictured.
1
Function selector
Display
Temperature selector
Touch fields
Temperature control
Buttons
You can use the buttons to directly select various functions.
Note: If a button is not operational, a signal tone sounds.
Symbol Button
Time-setting options
Minus
Plus
Lighting
Rapid heating
Childproof lock
Display
You can see the current setting values or options in the
display.
5
Use the function selector to set the type of heating or other functions. You can
turn the function selector clockwise or anti-clockwise from the zero setting.
The display shows symbols for active functions and the time-setting options.
Use the temperature selector to set the temperature for the type of heating or se-
lect the setting for other functions. You can turn the temperature selector clock-
wise and anti-clockwise. It does not have an off position.
You can use the touch fields to set various functions directly.
The temperature indicator bars show the heating phases or residual heat in the
cooking compartment.
Explanation
Set the timer, cooking time, end time or time
Decrease the setting value
Increase the setting value
Switch the interior lighting on or off
Switch the rapid heating on and off
Activate and deactivate the childproof lock in standby mode
Familiarising yourself with your appliance en
2
4
The value that you can currently set is in focus. The
value is displayed in white lettering with a dark back-
ground.
3
