Position the hearth in the proper place.
Connect the Multi-Vent system. If you wish to use the heater as a
wall-mounted
section
Place the concentric pipes in the connector at the rear of the hearth,
if you are using wall or roof venting. If you wish to install the Multi-
Vent gas hearth first, you can also use a fitting piece for the
connection between the Multi-Vent gas hearth and the Multi-Vent
system. This fitting piece should be ordered separately.
If you are using an existing chimney, you should first draw the
flexible inner pipe (ø 100 mm) with the outer pipe through the
chimney connector plate and then fasten it to the Multi-Vent gas
hearth's flue gas exhaust using a clamping strip. You can then push
the outer pipe into the combustion air intake pipe.
Connect the hearth to the gas supply.The appliance is fitted with a
pressure regulator.
Check all the gas connections for leaks. Use soapy water and/or a
gas-leak detector.
Usingthe clamp, fit the thermostat sensor supplied in a cool place
close to the hearth - on the skirting board, for example.
The barrier plate at the rear of the hearth should be removed in the
following
2-10m
5 INSTALLING THE HEARTH
heater, connect it in accordance
6.
cases:
1. When the height Of the pipe is between two
and ten
2. When the exhaust pipe goes directly
through the external wall to the outside
(see also H6, wall-mounted heater exhaust).
with the instructions
meters.
