5 Technical data
5.1 Electrical system
Note!
The following values apply for all control units:
– Permissible flow temperature:
– Permissible operating temperature:
– Permissible ambient temperature:
Type Power output
(kW)
Servimat M 1.1
Servimat L 1.1
5.2 Dimensions and connections
Type Weight
(kg)
Servimat M 46
Servimat L 57
5.3 Operation
Type System volume
(100% water)
(m³)
Servimat M 220
Servimat L 220
Standard values for the maximum "Va" system volume to be degassed under
extreme conditions during commissioning at a nitrogen reduction from 18 mg/l to
10 mg/l.
1 [h]
Continuous degassing "t"
5.4 Tanks
Primary tank
Power supply Degree of
(V / Hz , A) protection
230 / 50, 5 IP 54
230 / 50, 5 IP 54
Height Width
(mm) (mm)
1159 729
1151 572
System volume
(50% water 50% glycol)
(m³)
–
–
2 System volume "Va" [m ]
3
Secondary tank
Servimat M/L — 25.07.2024
120 °C
70 °C
0 °C – 45 °C
Number of RS- I/O
485 interfaces module
1 No
1 No
Depth Device
(mm) connection
653 Internal thread 1 "
653 Internal thread 1 "
Working pressure Permissible operating
(bar)
0.5 – 4.5
0.5 – 7.2
 Note!
Optional heat insulation is available for primary tanks,  4.6 "Optional
equipment and accessories",  32.
Type Ø "D"
(mm)
6 bar - 200 634
6 bar - 300 634
6 bar - 400 740
6 bar - 500 740
6 bar - 600 740
6 bar - 800 740
6 bar - 740
1000/740
6 bar - 1000
1000/1000
6 bar - 1200
1500
6 bar - 1200
2000
6 bar - 1500
3000
6 bar - 1500
4000
6 bar - 1500
5000
Electrical voltage Noise level
control unit
(V, A)
230, 2
230, 2
Degassing
system
connection
Internal thread 1 "
Internal thread 1 "
Operating temperature
gauge pressure
(bar)
8
10
Weight Connection H
(kg) (inches) (mm)
37 G1 1060
54 G1 1360
65 G1 1345
78 G1 1560
94 G1 1810
149 G1 2275
156 G1 2685
320 G1 2130
465 G1 2130
565 G1 2590
795 G1 2590
1080 G1 3160
1115 G1 3695
Technical data
(dB)
55
55
Make-up
connection
Internal thread ½ "
Internal thread ½ "
(°C)
>0 – 70
>0 – 70
h
(mm)
146
146
133
133
133
133
133
350
350
350
380
380
380
