Electric Wiring and the Application
• Power cable must be fixed firmly.
• To avoid electrical shock, make sure to disconnect the power supply 1 minute or more before servicing the electrical
parts.Even after 1 minute,always measure the voltage at the terminals of main circuit capacitors or electrical parts and
before touching, make sure that those voltages are 50VDC or less.
• To persons in charge of electrical wiring work: Do not operate the unit until the water pipe is complete. (Running it before
the piping is ready will break the compressor)
• Each outdoor must be earthed well.
• The appliance shall be installed in accordance with national wiring regulations.
• All wiring must be performed by an authorized electrician.
• Be sure to install an earth leakage circuit breaker in accordance with applicable legislation.Failure to do so many cause
electrical shock.
Outdoor power input
Model
AW042MUGHA
AW062MUGHA
AW082MUGHA
AW102MUGHA
AW122MXGHA
AW142MXGHA
AW162MXGHA
AW10NMUGHA
AW12NMXGHA
AW14NMXGHA
AW16NMXGHA
(1) Water 12/7°C - Outdoor 35°C
(2) Water 40/45°C - Outdoor 7°C DB/6°C WB
Communication wire to ATW-A03N
Length of Signal Line (m)
≤1000
• The shielding lay of the signal line must be grounded at two side.
COOLING(1)/kW
0.73
1.12
1.50
1.96
2.35
2.83
3.23
1.96
2.35
2.85
3.23
Wiring Dimensions
2
0.75mm
× 2 core shielding line
31
HEATING(2)/kW
0.90
1.39
1.83
2.41
2.80
3.37
3.94
2.41
2.80
3.37
3.94
MAX/kW
2.9
2.9
4.0
4.0
6.6
6.6
7.5
4.0
6.6
6.6
7.5
