• Repairs carried out by third parties, unauthorised spe-
cialists
• Installing and replacing non-original spare parts
• Improper use
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product
as described and for the specified areas of application.
Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2 Product description (Fig. 1-22)
1. Steering
2. Drive bow
3. Engine brake lever
4. Upper push bar
5. Quick clamp lever
6. Plastic star grip nut
7. Cable clip
8. Lower push bar
9. Guide (push bar)
10. Fuel filler cap
11. Fuel tank
12. Air filter cover
12a. Air filter
13. -
14. Water connection
15. Idler
16. Spark plug connector
16a. Spark plug
17. Exhaust pipe
18. Oil dipstick
19. Side discharge flap
19a. Side discharge
20. Cutting height adjustment
21. Drive wheel
22. Discharge flap
23. Grass collection basket
24. Rope hook
25. Pull starter
26. Mulching insert
27. Blade
28. Blade screw
29. Washer
30. Engine spindle
31. Carburettor screw
32. V-belt
3 Scope of delivery (Fig. 1-2)
Item QuantityDesignation
4. 1 x Petrol lawnmower with upper push bar
5. 2 x Quick clamp lever
6. 4 x Plastic star grip nut
7. 1 x Cable clip
8. 1 x Lower push bar
9. 2 x
19a. 1 x
23. 1 x
26. 1 x
A. 2 x
B. 2 x
C. 2 x
D. 2 x
1 x
4 Proper use
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
The product may only be operated with original parts and
original accessories from the manufacturer.
The safety, operating and maintenance specifications of
the manufacturer, as well as the dimensions specified in
the technical data, must be observed.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
WARNING
For your own safety, please thoroughly read this manu-
al and the general safety instructions before turning the
product on. If you give the product to third parties, al-
ways include these usage instructions.
Explanation of the signal words in
the operating manual
DANGER
Signal word to indicate an imminently haz-
ardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in death or serious injury.
CAUTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in minor or moderate injury.
www.scheppach.com
Guide (push bar)
Side discharge
Grass collection basket
Mulching insert
Screw M8
Washer, small
Washer, large
Spacer
Operating manual
