Remontagem do assento do passageiro
Lubrifique a sede (V1) do pino (S7) com SHELL GADUS S2 V220
AD 2.
Coloque o assento do passageiro (S1) e introduza a lingueta (S8)
no alojamento (V2) presente no interior do compartimento porta-
objetos.
Empurre o assento do passageiro (S1) para baixo para bloquear o
pino (S7) na fechadura do assento.
Certifique-se do engate correto, puxando suavemente o assento
do passageiro (S1) para cima.
Retire a chave da fechadura.
ISTR 780 / 00
S8
V2
S1
Passenger seat reassembly
Lubricate the seat (V1) of the pin (S7) with SHELL GADUS S2 V220
AD 2.
Position passenger seat (S1) and insert the tab (S8) into the
housing (V2) present inside the glove compartment.
Push the passenger seat (S1) downwards to secure the pin (S7) in
the seat lock.
Make sure that the passenger seat (S1) is properly secured by
gently pulling it upwards.
Remove key from the lock.
S7
V1
