For cutting:
Material
Plywood 1-3 mm
Plywood 4 mm
Plywood 5 mm
Plywood 6 mm
Plywood 8 mm
Acrylic 1 mm
Acrylic 3 mm
Acrylic 6 mm
NOTE:
The energy value is set to 500, and the laser intensity accounts for 50 % of the power.
The energy value is set to 1000, and the proportion of laser intensity to power is 100 %.
The larger the energy, the faster the speed can be set.
The above parameters only for reference. Due to the different properties of the
materials, please adjust the parameter values according to the actual situations.
Machine testing guide
1. Turn on the machine and connect it to the computer.
2. Movement test:
Control the machine to move up down, left, and right on the software, check whether
the moving direction is correct (Figure A01), and check whether the moving distance is
correct (Figure A02).
3. Laser emission test:
The software imports the custom icon, click on the light (low light). Wear protective
glasses to observe whether the laser module emits blue light (Figure A03).
4. Test the files in the TF Card:
NOTE: Laser will generate heat and glare, which may cause harm. Please follow the
instructions to avoid injury.
Speed (mm/min)
700-1000
500
300
150
100
500
200
100
19
Power (%)
100
100
100
100
100
100
100
100
Times
1
1
1
1
1-2
1
1
1-2
