Instruction Manual
14
13. Unscrew the inspection cover in both corners and
unhook the counterweight behind it from the cord.
14. Unscrew the two camber plates.
15. Unscrew the counterweight box plates on both
sides.
16. Remove the firebox trough from the firebox.
17. Unscrew the door frame on both sides and separate
it from the rails.
18. Remove the insulation plate.
19. Unscrew or separate the remaining base body.
20. Separate the sealing strips from the counterweight.
21. Tear the sealing strips loose from the two compo-
nents.
22. Unscrew the door handle and the clamped ceramic
glasses.
