ruegg AXINIT Bedienungsanleitung Seite 45

AXINIT, LARIMAR
& ECO 720
1 Thermal insulation side wall [cm]
2 Thermal insulation rear wall [cm]
3 Thermal insulation floor [cm]
Safe spacing from flammable materials in the heat-radiation area
4
[cm]
5 Nominal heat performance [kW]
6 Thermal performance range [kW]
3
7 CO [%] + [mg/Nm ]
3
8 Dust [mg/Nm ]
9 Efficiency [%]
10 NO (13 % O )
x 2
11 OGC (13 % O )
2
Key indicators of the test centre responsible and accredited for the
12
test
13 Standard in accordance with which the fireplace insert was tested
14 Designation of the fireplace insert
Multiple use of the fireplace is permitted only with a self-closing
15
door
16 May be operated strictly as a temporary-burning fireplace (INT)
17 Read and follow the operating manual
18 Sole recommended fuel: Natural wood
19 Address of the manufacturer
20 Description and generation of the fireplace insert
21 Serial number
22 Specification of the reference insulation stone wool
23 Front / side
24 Nominal heat performance [kW]
3
25 CO [%] + [mg/Nm ]
3
26 Dust [mg/Nm ]
27 Efficiency [%]
28 NO (13 % O )
x 2
29 OGC (13 % O )
2
30 The narrower side (2-seitig)
31 Date of manufacture
Instruction Manual
43
Based on test report in accordance with EN 13229
Based on test report in accordance with EN 13229
Based on test report in accordance with EN 13229
Based on test report in accordance with EN 13229
Based on test report in accordance with EN 13229
Based on test report in accordance with EN 13229
Based on test report in accordance with EN 13229
Based on test report in accordance with EN 13229
Based on test report in accordance with EN 13229
Based on test report in accordance with EN 13229
Based on test report in accordance with EN 13229
W = only wood products are permitted
A = storage operation permitted
Measured according to EN 16510-1
Measured according to EN 16510-1
Measured according to EN 16510-1
Measured according to EN 16510-1
Measured according to EN 16510-1
Measured according to EN 16510-1
Left / Right
Day / month / year
