Commissioning - ruegg AXINIT Bedienungsanleitung

AXINIT, LARIMAR
& ECO 720

12 Commissioning

Take your system into service for the first time in conjunction with a specialist installer. He will explain in
detail the functions and how to handle the operating elements. The materials of the casing must be com-
pletely dry during initial commissioning. Increase the volume of fuel added to the maximum quantity in
three steps.
Foreign odours!
The colour of the fireplace insert must be fully baked in during the initial firings. This is why
your system may give off unpleasant odours.
•
Open all windows in the installation area
•
Close all doors in the installation area
Strange sounds!
Thermal expansion of the various materials on the fireplace insert may result in cracking or
ticking sounds as it heats up or cools down. These sounds are not dangerous and do not af-
fect the operational safety and functionality of your system!
12.1 Complete Combustion
After a complete burn-up, only ash and small pieces of coal remain in the combustion chamber. Complete
combustion of firewood is always divided into three phases.
Phase 1: Drying out
The residual humidity in the firewood evaporates at temperatures above 100°C.
Phase 2: Outgassing
The volatile elements of the firewood make up around 85 % of the wood. These volatilise and ignite at
temperatures above 230°C.
Phase 3: Combustion
The burning charcoal equates to around 15 % of the energy content and burns without any visible flame
at temperatures above 800°C.
12.2 Reduce Harmful Substances
Make an active contribution to reducing harmful emissions with a little effort. The most important mea-
sures here are:
•
Fire with top-down combustion
•
Use permitted fuels
•
Keep to the feed quantity
•
Burn several smaller logs instead of one large log
•
Adjust the operating elements to the particular operating state
12.3 Firing Module
Instruction Manual
Firelighter
Fir (200 - 400 g)
Hardwood cross stack
A firing module forms the basis for firing with top-down
combustion. The fire burns out from the top down. Harmful
emissions are greatly reduced during fire-up using this
method. The overall quantity should not exceed the permit-
ted loading quantity. Assemble the firing module as shown.
34
