Instruction manual FM-IM / FMX-IM
DANGER
Dangerous voltages on the connection terminals
Instantaneously possible personal injuries with devices FM-IM-3UR38X and

FMX-IM-3UR38X

➤ Please adhere to the respective safety regulations during connection.
➤
IMPORTANT INFORMATION
Distances between device and sensor
The length of the electrical connection between the flow sensor and the device
may be max. 100 m. With lengths exceeding 30 m a shielded sensor cable is
recommended. In either case it should be checked whether the chosen wire
width meets the requirements.
Function
Sensor Supply
Heated Pt1000
GND
Unheated Pt1000
Voltage Supply
PNP 1 (Out 1)
PNP 2 (Out 2)
PNP 3 (Out 3)
Relay
1 (Out 1)
Relay
2 (Out 2)
Relay
3 (Out 3)
Current Source
IO-Link
HART®
Table 5:
22
FM(X)-IM-3UP63X
Terminal 1
Terminal 2
Terminal 3
Terminal 4
Terminal 19 (+)
Terminal 20 (−)
Terminal 12
Terminal 13
Terminal 14
Terminal 12,
alternative via female
connector COM (PC)
Terminal assignment
Hans Turck GmbH & Co. KG • Tel. +49 (0) 208/4952-0 • Fax +49 (0) 208/4952-264
FM(X)-IM-3UR38X
Terminal 1
Terminal 2
Terminal 3
Terminal 4
Terminal 19 (+)
Terminal 20 (−)
Terminals 12 and 13
Terminals 14 and 15
Terminals 17 and 18
via female connector
COM (PC)
FM(X)-IM-2UPLi63X
Terminal 1
Terminal 2
Terminal 3
Terminal 4
Terminal 19 (+)
Terminal 20 (−)
Terminal 13
Terminal 14
Terminal 11 (+)
Terminal 16 (−)
Only with non-ex-
device via terminal 12,
alternative via female
connector COM (PC)
Only with Ex-device via
terminals 11 and 16,
alternative via female
connector COM (PC)
