Instruction manual FM-IM / FMX-IM
7

setting and Parametrization

7.1

Parametrization via pushbuttons

IMPORTANT INFORMATION
Termination of the Teach-Mode
By simultaneously pushing the "Set" button and the "Mode" button, the Teach-
Mode and the Quick-Teach-Function can be interrupted at any time. The device
automatically skips back to the last display mode of flow monitoring.
IMPORTANT INFORMATION
Parametrization is not possible during the heating phase
After start-up or connection of a sensor, the device is automatically in the
heating phase (see Chapter 3.5.3 on p. 15).
7.1.1

Devices with switching output

(FM(X)-IM-3UP63X, FM(X)-IM-3UR38X)
(menu structure Figure A, see inside front cover)
Switchpoint setting of flow monitoring (SP flow in the menu structure)
IMPORTANT INFORMATION
No DeltaFlow-Monitoring with relative values
DeltaFlow-Monitoring has no significance for setting the switchpoint, because
it involves Parametrization of a relative value that relates to the following max/
min-settings.
➤ In the display mode (Flow Display), push the "Mode" button one time.
➤
The switchpoint setting of flow monitoring (SP Flow) starts, the display is
yellow, the LED "Flow" is blinking.
➤ Push the "Set" button for 5 s (equals 5 × blinking).
➤
Wait until the display is yellow again.
➤ Push in increments the "Set" button or push in increments the "Mode"
➤
button (Set SP Flow).
Pushing the "Set" button increases the switchpoint by 10 % at a time.
Pushing the "Mode" button decreases the switchpoint by 10 % at a time.
➤ Push the "Enter" button one time.
➤
The switchpoint is stored.
26
