Instruction manual FM-IM / FMX-IM
9

technical data

Non-Ex-Devices
Function
Operating Voltage
Supply
Nominal Voltage 24 VDC
Power
Consumption
No-Load Cur-
rent I₀
Display Modi
Temperature
Range
Sensors Voltage
Sensor Current
Current limit to
Sensor
Measurement
Input
Measurement
Frequency
Switching
Outputs¹
Switching
Characteristic
38
FM-IM-3UP63X
20...30 VDC
< 4.5 W
≤ 63 mA
Flow Rate [%] per
Min-/Max Setting
(permanent)
Flow Rate [%] per
Quick Teach (perma-
nent)
Temperature of
medium [°C] when
"Set" button is pushed
(temporary)
−25...70 °C
≤ 15 VDC
≤ 35 mA
ca. 110 mA
no connection of
an active voltage,
measurement size is
generated by feeding
the measurement
cables
5 Hz
(all 200 ms with
Software filtering)
Transistor Output 1 ✓
(Flow Monitoring),
Transistor Output 2 ✓
(Temperature
Monitoring),
Transistor Output 3 ✗
(Error Monitoring)
PNP
Hans Turck GmbH & Co. KG • Tel. +49 (0) 208/4952-0 • Fax +49 (0) 208/4952-264
FM-IM-3UR38X
20...250 VAC/
20...125 VDC
< 4 W
≤ 63 mA
Flow Rate [%] per
Min-/Max Setting
(permanent)
Flow Rate [%] per
Quick Teach (perma-
nent)
Temperature of
medium [°C] when
"Set" button is pushed
(temporary)
−25...70 °C
≤ 15 VDC
≤ 35 mA
ca. 110 mA
no connection of
an active voltage,
measurement size is
generated by feeding
the measurement
cables
5 Hz
(all 200 ms with
Software filtering)
Relay Output 1 ✓
(Flow Monitoring),
Relay Output 2 ✓
(Temperature
Monitoring),
Relay Output 3 ✗
(Error Monitoring)
Relay
FM-IM-2UPLi63X
20...30 VDC
24 VDC
< 4.5 W
≤ 63 mA
Flow Rate [%] per
Min-/Max Setting
(permanent)
Temperature of
medium [°C] when
"Set" button is pushed
(temporary)
−25...70 °C
≤ 15 VDC
≤ 35 mA
ca. 110 mA
no connection of
an active voltage,
measurement size is
generated by feeding
the measurement
cables
5 Hz
(all 200 ms with
Software filtering)
Transistor Output 2 ✓
(Temperature
Monitoring),
Transistor Output 3 ✗
(Error Monitoring)
PNP
