For temperature monitoring all devices have a switching output (Out 2 (Temp)).
The devices change their switching status when the set switchpoint has been
reached with the rise in temperature. If the temperature falls, the switching
status changes when the switchpoint is underreached by the hysteresis (2 K) .
The switchpoint is teachable.
The following default values are valid for the temperature monitoring function
of the device:
■
Operating range: −42...184 °C
■
Display range: −22...179 °C
■
Switchpoint: 70 °C
■
Hysteresis: 2 K
■
Measurement accuracy: typical ± 7 K
■
Repeat accuracy: typical ± 1 K
■
Out 2: "Active high" (transistor) or closer (relay)
3.4

Parametrization possibilities

The devices are adjusted to the respective installation situation via Paramet-
rization. Parametrization is possible with the help of pushbuttons or via soft-
ware.
IMPORTANT INFORMATION
Parametrization is not possible during the heating phase
After start-up or connection of a sensor, the device is automatically in the hea-
ting phase (see Chapter 3.5.3 on p. 15).
3.4.1

Pushbutton Parametrization

Parametrization with the help of pushbuttons occurs in the Teach-Mode as
guided cycle.
In regard to flow monitoring, the Parametrization possibilities depend on the
respective device type; in regard to temperature monitoring, all devices have a
settable switchpoint for temperature monitoring.
For devices with switching output for flow monitoring, the switchpoint for flow
monitoring is settable, together with the limits of the monitored display range.
Setting of the switchpoint without the additional setting of the display range
is possible via the Quick-Teach-Procedure and as an alternative to the guided
cycle.
For devices with current output for flow monitoring, the limits of the monitored
display range are settable.
