Instruction manual FM-IM / FMX-IM
7.2
Tool-based engineering via FDT/DTM
By operating the devices together with a master, additional functions for
process monitoring and evaluation are available, as well as the possibility of
device Parametrization via the PC.
Here is a selection of functions that are also available by operating the devices
together with a master:
■
Process data monitoring (display of process values)
■
Detailed diagnostic possibilities and display of all error states
■
Quantitative and qualitative display of DeltaFlow-Monitoring
■
Display of all available device parameters
■
Execution of Teach-Procedures via interactive pushbuttons.
■
Trend display with the possibility to cyclically display the process data for
a defined time period – following storing and exporting of the recorded
process data.
■
Documentation of the parameter sets and of general or specific device
information.
The possibilities and functionality of the software-supported device Parametri-
zation and operation are explained in Chapter 3.4.2 on p. 12 and in Chapter
3.4.3 on p. 13.
IMPORTANT INFORMATION
Parametrization is not possible during the heating phase
After start-up or connection of a sensor, the device is automatically in the
heating phase (see Chapter 3.5.3 on p. 15).
7.2.1
IO-Link-Communication
The signal processors FM(X)-IM-3UP63X, FM(X)-IM-3UR38X and FM-IM-2UP-
Li63X are equipped with the IO-Link communication protocol. If the device is
active in the IO-Link mode, the „Pwr" LED blinks (see Chapter 4.2 on p. 16).
All signal processors can be connected to the IO-Link-Master via the 3.5 mm
jack plug COM (PC) on the front side. With the devices FM(X)-IM-3UP63X and
FM-IM-2UPLi63X, it is possible to chose a connection via Terminal 12 or via the
female connector (see Chapter 6 on p. 21) on the front side. For connection
via the 3.5 mm jack plug COM (PC), the communication cable IOL-COM/3M
(Ident-No. 7525110) is needed.
Please refer to document "IO-Link-Parameter – FM-IM / FMX-IM" (D101920)
for the parameters to operate the devices via IO-Link. Please refer to the start-
up instruction "Getting started – FDT/DTM Frame PACTware™ with IO-Link"
(D101931) for the installation of the required frame application.
These documents are online in PDF format.
36
