6100−44−12 Optional Head Extension Assembly
Item Part No. Part Name
A 6100−44−10 Bracket Weldment
B 6100−44−7 Support
C 6100−44−11 Extension Tube
D 6100−44−8 Pillow Support
E 6100−44−5 Insert
F 28−76 Clip
G 6100−44−6 Spacer
H 16−28 Nylock Nut
J 4−161 But. Hd. Cap Screw
K 4−232 But. Hd. Cap Screw
Qty. Item Part No.
1 L (page 66)
1 M 25−79
1 N 14−67
2 P 25−31
1 R 6060−90−4
2 S 6100−90−13
2 T 6100−44−13
4 V 6100−44−4
2 W 45−999−603
2 X 6100−44−14
65
Part Name Qty.
Pull Pin Assembly 1
Rivet 4
Washer 4
Semi−Tubular Rivet 4
Small Rugged Label 1
Specification Label 1
Velcro Hook 1
Insert 1
O−Ring 2
Tape 3
