Pro II: Profibus/Profinet-Schnittstelle
P2_Init_ProfinetIO
346
Beispiel
#Include ADwinPro_All.inc
#Define out_arr Data_2
#Define in_arr Data_3
module
#Define 3
Dim out_arr[1000] As Long
Dim in_arr[1000] As Long
Dim conf_arr[AB_WORK_ARR_LEN]
Dim i As Long
Dim state As Long
LowInit:
Processdelay = 3000000
Rem init Profinet interface: input data area = 128 DWords
Rem and output data area = 256 DWords
Par_10 = P2_Init_ProfinetIO(module, 128, 256, conf_arr)
Event:
Rem set data in out_arr[] to be transferred
For i = 1 To 256
out_arr[i] = (out_arr[i] + i)
Next i
Rem send and read data, flowrate slow
state = P2_Run_ProfinetIO(module, out_arr, in_arr, 128, 256,
conf_arr, 1)
Par_2 = state
Rem now process received data stored in in_arr[1..128];
Rem in_arr[129..1000] remains unused here.
ADwin
As Long
'set to 100 Hz
