JÄGER ADwin-Pro II Systembeschreibung Seite 143

ADwin
Gültig für
AOut-1/16 Rev. E
Beispiel
#Include ADwinPro_All.inc
#Define module 5
#Define dac_no 1
Dim array[5] As Long
Dim ramp_no, v_start,
Init:
Rem stop possibly running ramp
P2_DAC_Ramp_Stop(module,
Rem define values for 4 ramps
array[1] = 0
array[2] = 16384
array[3] = 57344
array[4] = 32768
array[5] = 49152
ramp_no = 1
Event:
Rem check if buffer has free space
If (P2_DAC_Ramp_Buffer_Free(module,dac_no) >= 0)
v_start = array[ramp_no]
v_end = array[ramp_no+1]
Rem write ramp, set ramp time 1.5µs, no digital values
P2_DAC_Ramp_Write(module,dac_no,v_start,v_end,0,0,1500,001b)
Inc ramp_no
If (ramp_no > 4)
EndIf
ADwin-Pro II Software, Handbuch Apr. 2021
v_end As Long
dac_no)
'-2.0 V
'-1.0 V
'+1.5 V
' 0.0 V
'+1.0 V
Then ramp_no = 1
Pro II: Analoge Ausgänge
P2_DAC_Ramp_Write
Then
139
