Pro II: Digitale Ein-/Ausgänge
P2_Comp_Init
146
Beispiel
#Include ADwinPro_All.inc
#Define module 2
Dim Bit_Ch_0, Bit_Ch_0_1
Init:
P2_Comp_Init(module,1,3)
Rem Set thresholds: channel group 1 to 0V, channel group 2 to 10V
P2_Comp_Set(module,1,Volt2Digits(0.0))
P2_Comp_Set(module,2,Volt2Digits(10.0))
Rem Set thresholds in volts directly
'P2_Comp_Set_Voltage(module, 1, 0.0)
'P2_Comp_Set_Voltage(module, 1, 10.0)
Rem Set filter to length 200 ns
P2_Comp_Filter_Init(module, 10)
Event:
Rem check comparator bits
Par_1 = P2_Digin_Long(module)
Rem channel 1
Bit_Ch_0 = Par_1 And
Rem free hysteresis determined by channels 0, 1
Bit_Ch_0_1 = Shift_Right(Par_1,16)
If (Bit_Ch_0 = 1)
Rem channel 0 > 0 V
Else ' (Bit_Ch_0 = 0)
Rem channel 0 < 0 V
EndIf
If (Bit_Ch_0_1 = 1)
Rem both channels 0, 1 > 10 V
Else ' (Bit_Ch_0_1 = 0)
Rem both channels 0, 1 < 0 V
EndIf
Function Volt2Digits(volt)
Volt2Digits = volt
EndFunction
As Long
'set channels 0..3 to hold 200µs
1b 'threshold of channel 0
And
Then
Then
As Long
* (65536 / 60) + 32768
