Pro II: RSxxx
P2_Write_Fifo_Full
336
Beispiel
Rem sending data to and receiving data from the PC while using
Rem a Fifo in ADwin-Pro II
#Include ADwinPro_All.inc
#Define outfifo Data_1
#Define infifo Data_2
#Define rs_adr 5
#Define rs_channel 1
Dim outfifo[1000] As Long As Fifo
Dim infifo[1000] As Long As Fifo
Dim value, dummy, check
Rem use LED as signal: red = sending, green = receiving,
Rem orange (red+green) = sending + receiving
Dim red_led, green_led
Dim green_led_time As Long
Dim led_time As Long
Init:
Rem reset and initialize channel
P2_RS_Reset(rs_adr)
P2_RS_Init(rs_adr, 1, 9600, 0, 8, 0, 0)
Fifo_Clear(1)
Fifo_Clear(2)
green_led = 0
red_led = 0
Event:
Rem sending
If (Fifo_Full(1) > 0)
If (P2_Write_Fifo_Full(rs_adr, rs_channel) = 0)
Rem send Fifo empty?
value = outFifo
dummy = P2_Write_Fifo(rs_adr, rs_channel, value)
Rem dummy is not to be checked, since Write_Fifo_Full has
Rem proved that Fifo has empty elements.
'do LED settings
If (red_led = 0)
red_led = 1
led_time = Read_Timer()
EndIf
EndIf
EndIf
Rem receiving
If (Fifo_Empty(2) > 0)
check = P2_Read_Fifo(rs_adr, rs_channel)
If (check <> -1)
inFifo = check
'do LED settings
If (green_led = 0)
green_led = 1
led_time = Read_Timer()
EndIf
EndIf
EndIf
'output LED settings
dummy = (red_led And
As Long
As Long
Then 'any data present?
'read value from Fifo
Then
Then 'are there empty elements?
Then 'is a value in the receiving buffer?
'get value into inFifo
Then
1) Or Shift_Left(green_led
ADwin-Pro II Software, Handbuch Apr. 2021
ADwin
Then
And 1, 1)
