V-3 INSTALLATION OF THE DRAINING SYSTEMS

V-3-1-Description of the essential functional elements

OPEN 5.5
3
5 1
OPEN 7
5 1
2
Ref.
1 Engine recess drain
2 Hull scupper
3 Bilge pump outlet
4 Bilge pump
5 Through-hull with membrane
6 Thru-hull plug
INSTALLATION AND CIRCUIT - DRAINING
