V -10-FIXATION UPHOLSTERY
Your boat is equipped with a new type of fixation (1) to maintain the upholstery on the hull. This
system provides magnets with a lateral unlocking (2).
➢ Unlocking: Slightly pull the retaining strap (3) downwards and make it slide to the side.
➢ Locking: Slightly pull the retaining strap (3) downwards and make it slide to the interior of
the fixation.
INSTALLATION AND CIRCUIT – Upholstery
3
WARNING
Do not pull directly on the upholstery to unclip it, as this will damage
the new fixation system.
1
2
