Ref.
1 Battery connection
2 Bilge fan connection
3 Circuit breaker connection
4 Bus bar ground connection
5 Bilge pump connection
6 Bilge fan switch connection
7 Bilge pump switch connection
8 Navigation light switch connection
9 White light connection
Fuel gauge dial connection
10
11 Red green light connection
12 Fuel gauge transmitter connection
13 Positive bus bar connection
14 12 Volt power socket connection (console)
15 USB port connection
16 3A fuse, USB port
5A fuse, 12-volt outlet
17
18 5A fuse, navigation lights
19 5A fuse, bilge fan
20 5A fuse, bilge pump
INSTALLATION AND CIRCUIT: ELECTRICAL
Purple 4 AWG18
Purple 3 AWG18
Red 6 & 7 AWG18
Red 5 AWG16
Red 3 AWG10
