6 Maintenance / checks
6.1 Maintenace activities – operator
The following points must be checked and carried out
after the installation of the door and every 6 months:
• Always grease the roller axes after
approx. 5000 door actuations. Clean horizontal
rail pairs.
• Do not apply oil on the lock cylinder. In case it
does not run smoothly enough, treat with
graphite spray.
• Ensure sufficient ventilation (drying) of the door
frame. Water drainage must also be ensured.
• Protect the sectional door from caustic and
aggressive agents such as acids, lyes, thawing
salts etc. Only use mild household cleaning agents.
• Steel-filled sectional garage doors are coated
with polyester at the factory. Any paintwork on
site must be applied within 3 months from
delivery using 2C epoxy primer containing
solvents and, once hardened, standard paint.
• Touch up the paint at intervals as required by
local environmental and atmospheric conditions.
6.1.1 Cleaning
We recommend wiping the door regularly with a soft,
damp cloth. If necessary, use a mild cleaning agent
or soap with lukewarm water. Avoid using any polish-
ing agents or abrasive or organic solvents/cleaning
agents. Before cleaning, flush the door and glazing
thoroughly with water to avoid scratches caused by
dust particles.
6.2 Maintenance activities – competent
person
The following maintenance activities may only be car-
ried out by a competent person, see chapter 2.3 -
Personnel qualifications.
• Check the door in accordance with the test
instructions.
• Check screws and clamping connections for tight
fit and retighten if necessary.
• Check wearing parts (springs, wire ropes etc.)
and replace with original spare parts, if
necessary.
• Make sure that the spring tension is correct. If it is
necessary to adjust the spring tension, proceed in
accordance with the assembly instructions.
• Replace multiple spring assemblies and double
wire ropes after approx. 25,000 door operations
(open/close movements).
This is equivalent to approx.:
Door actuations per day
0 - 5
6 - 10
11 - 20
These assembly, operation and maintenance instructions must be kept for the entire period of use!
7
7.1
1. Disassembly may only be carried out by a com-
2. Never carry out the disassembly on your own.
3. Move the door leaf to its open end position and
4. Unhook the single wire ropes from the lower
5. Further steps for disassembly are carried out in
8
Dispose of packaging material in an environmentally
friendly way and in accordance with the applicable
local disposal regulations.
waste electrical or electronic equipment stipulates
that this equipment must not be disposed of with the
household waste at the end of its life. You will find
collection points for free return of waste electrical and
electronic equipment in your vicinity. The addresses
can be obtained from your municipality or local ad-
ministration. The separate collection of waste elec-
trical and electronic equipment aims to enable the re-
use, recycling and other forms of recovery of waste
equipment as well as to prevent negative effects for
the environment and human health caused by the
disposal of hazardous substances potentially con-
Replace
tained in the equipment.
every 14 years
every 7 years
every 3.5 years

Disassembly

Safety instructions for disassembly

Hazardous tensioned springs
WARNING
Springs are under high tension and can
release large forces when being ten-
sioned or when being relieved from ten-
sion.
• Wear suitable personal protective
equipment when relieving springs
from tension.
Impact and crush hazard caused by
WARNING
the door sinking!
When unhooking the tension springs,
the door leaf may sink.
• Secure the door leaf against sinking
when unhooking the tension springs.
petent person, see chapter 2.3 - Personnel qual-
ifications.
Some of the work steps can only be achieved
with two people working.
secure it against falling.
rope swing device on the left and right and
slowly and carefully close the door.
reverse order of the assembly instructions.

Disposal

The symbol with the crossed-out waste bin on
EN - 27
