ERROR MALFUNCTION
CODE OR PROTECTION
Indoor unit EEprom failure
Communication fault between
indoor unit and outdoor unit
Refrigerant liquid
temp.sensor(T2) fault
Refrigerant gas
temp.sensor(T2B) fault
Room temp.sensor(Ta) fault
Outlet water for z one 2
temp.sensor (Tw2) fault
Outlet water
temp.sensor(Tw_out)
fault
|Tw_out - Tw_in| value too
big protection
Anti-freeze mode
Tw_out - Tw_in unusual
protection
FAILURE CAUSE
AND CORRECTIVE ACTION
1. The EEprom parameter is error, rewrite the EEprom data.
2. EEprom chip part is broken, change a new EEprom chip
part.
3. main control board of indoor unit is broken, change a new
PCB.
1.wire doesn't connect between outdoor unit and main control
board of indoor unit. connect the wire.
2.Communication wire sequence is not right. Reconnect the
wire in the right sequence.
3. Whether there is a high magnetic field or high power
interfere, such as lifts, large power transformers, etc.. To add a
barrier to protect the unit or to move the unit to the other place.
1.Check the resistance of the sensor
2.The T2 sensor connector is loosen. Re connect it.
3.The T2 sensor connector is wet or there is water in. remove
the water, make the connector dry. Add waterproof adhesive
4. The T2 sensor failure, change a new sensor.
1.Check the resistance of the sensor
2. The T2B sensor connector is loosen. Reconnect it.
3.The T2B sensor connector is wet or there is water in. remove
the water, make the connector dry. Add waterproof adhesive
4. The T2B sensor failure, change a new sensor.
1.Check the resistance of the sensor
2. The Ta senor is in the interface;
3. The Ta sensor failure， change a new sensor or change a
new interface, or reset the Ta, connect a new Ta from the
indoor unit PCB
1.Check the resistance of the sensor
2. The T1B sensor connector is loosen. Reconnect it.
3.The T1B sensor connector is wet or there is water in.
Remove the water, make the connector dry. add waterproof
adhesive
4. The T1B sensor failure, change a new sensor.
1. The TW_out sensor connector is loosen. Reconnect it.
2.The TW_out sensor connector is wet or there is water in.
remove the water, make the connector dry. add waterproof
adhesive
3. The TW_out sensor failure, change a new sensor.
1. Check that all shut off valves of the water circuit are
completely open.
2. Check if the water filter needs cleaning.
3. Refer to "8.6 Filling water"
4. Make sure there is no air in the system (purge air).
5. Check on the manometer that there is sufficient water
pressure. The water pressure must be >1 bar(water is cold).
6. Check that the pump speed setting is on the highest speed.
7. Make sure that the expansion vessel is not broken.
8. Check that the resistance in the water circuit is not too high
for the pump. (refer to "9.4 Setting the pump" ).
Unit will return to the normal operation automatically.
1.Check the resistance of the two sensor
2.Check the two sensors locations
3.The water inlet/outlet sensor wire connector is loosen.
Reconnect it.
4.The water inlet/outlet （TW_in /TW_out） sensor is broken,
Change a new sensor.
5. Four-way valve is blocked. Restart the unit again to let the
valve change the direction.
6.Four-way valve is broken, change a new valve.
67
