turck TBEN-S Serie Betriebsanleitung Seite 223

Strom – Standard
Dezimal
Dezimal
V04.00 | 2021/05
hexadezimal
(Zweierkomplement)
Dez. Wert = 1638,35 (1/mA) × I
32767 7FFF
32766 7FFE
...
16384 4000
...
1 0001
0 0000
-1 FFFF
...
-16384 C000
...
-32767 8001
-32767 8000
hexadezimal
(Zweierkomplement)
Dez. Wert = 2047,9375 (1/mA) × (I
32767 7FFF
32766 7FFE
...
16384 4000
...
1 0001
0 0000
-1 FFFF
...
-16384 C000
...
-32767 8001
-32767 8000
(mA)
out
Nennbereich
...
...
...
...
(mA) – 4 mA)
out
Nennbereich
...
...
...
...
0...20 mA
20,0000 mA
19,9994 mA
...
10,0003 mA
...
0,0006103 mA
0,0000 mA
0,0000 mA
...
0,0000 mA
...
0,0000 mA
0,0000 mA
4...20 mA
20,0000 mA
19,9995 mA
...
12,00024 mA
...
4,0004883 mA
4,0000 mA
4,0000 mA
...
4,0000 mA
...
4,0000 mA
4,0000 mA
223
