9.3.2 Messwert-Darstellung – TBEN-S2-4AO
Spannung – Standard
Dezimal
Dezimal
V04.00 | 2021/05
hexadezimal
(Zweierkomplement)
Dez. Wert = 3276,7 (1/V) × U
32767 7FFF
32766 7FFE
...
16384 4000
...
1 0001
0 0000
-1 FFFF
...
-16384 C000
...
-32766 8001
-32767 8000
hexadezimal
(Zweierkomplement)
Dez. Wert = 3276,7 (1/V) × U
32767 7FFF
32766 7FFE
...
16384 4000
...
1 0001
0 0000
-1 FFFF
...
-16384 C000
...
-32767 8001
-32767 8000
(V)
out
Nennbereich
...
...
...
...
(V)
out
Nennbereich
...
...
...
...
-10...10 V
10,0000 V
9,9997 V
...
5,0002 V
...
0,000305 V
0,00000 V
-0,000305 V
...
-5,0000 V
...
-9,9997 V
-10,0000 V
0...10 V
10,0000 V
9,9997 V
...
5,0002 V
...
0,000305 V
0 V
0 V
...
0 V
...
0 V
0 V
