11 The Computer-Interface
TC-SYNTAX
Commands
Function
C
Cancels the complete entry since the last valid command
AxxxxAb
Allocation of an inertia level to a loco with FMZ- or TWIN-DECODER
or
•
A or a indicator that it handles an inertia command
axxxxab
•
xxxx is the 1 to 4 position address of the loco. It can be a virtual or
a digital address
•
b is the inertia level from 1 to 8
LxxxxLl
Lights on or off
or
•
L or I indicator that it handles a command to switch the lights
lxxxxlI
•
xxxx is the 1 to 4 position address of the loco. It can be a virtual
or digital address
•
I=1 to switch the light on (function), 0 = switches the light off
VxxxxVyy
Running command forwards
or
•
V or v indicator that it handles a command
vxxxxvyy
for forward speed
•
xxxx is the 1 to 4 position address of the loco.
It can be a virtual or digital address
•
yy is the always 2 position speed level (00 -15). If more speed steps are
allocated to the loco decoder, then automatically is ignored.
RxxxxRyy
Running command backwards
or
•
R or r indicator that it handles a command
rxxxxryy
for backward speed
•
xxxx is the 1 to 4 position address of the loco.
It can be a virtual or digital address
•
yy is the always 2 position speed level (00 -15).
If more speed steps are
allocated to the loco decoder, then automatically is ignored.
ExxxEs1s2
Switch an electrically operated accessory
or
•
E or e indicator that it handles a command
exxxes1s2
to switch an electrical accessory
•
is the 3 position digital address of the electrical accessory
receiver module. The virtual address of a point
cannot be used here.
•
s1=0 corresponding to green key, s1=1 corresponds to red key
•
s2 indicates the output of the electrical receiver module (1-4)
PssP
Execution of a point route in MEMO mode
or
•
P or p indicator that it handles a point route command
pssp
•
ss is the one or two position number of the point route from 1 to 48.
A tiny transposition is needed here. In MEMO mode there are three
groups each with up to 16 point routes, making a total of 48.
The point routes in group 1 will be controlled with ss=1 to 16, the
point routes of group 2 will be controlled with ss=17 to 32, the
point routes of group 3 will be controlled with ss=33 to 48.
