must learn how far the prosthetic foot swings forward when the prosthesis is lifted by the expansion springs. This
is very important especially for waking down stairs, in order to be able to precisely place the foot.
5

Additional information

5.1 Technical information

Sides
Proximal connection
Distal connection
Max. flexion angle
Weight of the joint
Weight of connection technology
System height
Material
Mobility Grade
Max. body weight
Operating and storage temperature range ­10 °C to +60 °C

5.2 Symbols on the hip joint

Declaration of conformity according to the European Directive for Medical Devices 93/42/EEC.

5.3 Legal information

All legal conditions are subject to the respective national laws of the country of use and may vary accordingly.

5.3.1 Liability

The manufacturer will only assume liability if the product is used in accordance with the descriptions and instruc­
tions provided in this document. The manufacturer will not assume liability for damage caused by disregard of
this document, particularly due to improper use or unauthorised modification of the product.

5.3.2 CE conformity

This product meets the requirements of the European Directive 93 / 42 / EEC for medical devices. This product
has been classified as a class I device according to the classification criteria outlined in Annex IX of the direc­
tive. The declaration of conformity was therefore created by the manufacturer with sole responsibility according
to Annex VII of the directive.

5.3.3 Trademarks

All product names mentioned in this document are subject without restriction to the respective applicable trade­
mark laws and are the property of the respective owners.
All brands, trade names or company names may be registered trademarks and are the property of the respective
owners.
Should trademarks used in this document fail to be explicitly identified as such, this does not justify the conclusion
that the denotation in question is free of third­party rights.
Helix
Right (R), Left (L)
Lamination plate
Pyramid adapter
130°
990 g
275 g
146 mm
Aluminium
2 + 3
100 kg
